Industrial valves for water & waste water technology banneroverlay

Industrial valves for
water & waste water technology

`

When water flows out of the taps in Austria’s second largest city, then on the 76.5 km long journey through the drinking water pipeline from the Hochschwab region, it has passed a series of pipe rupture valves (butterfly valves) from our manufacturer Erhard. But not only Graz, also other municipalities rely on our valves, which are suitable for drinking water and certified for water production and treatment, water distribution and industrial water supply.

For 100% tightness even under the greatest dynamic loads, we prefer to use products such as gate valves and butterfly valves in the drinking water sector instead of knife gate valves. Corrosion protection and clean water are guaranteed due to epoxy resin and enamel coatings as well as a special design.

Flowtec valves are also used in other areas where water is used as a medium, such as in hydropower plants, in desalination plants, in the waste water industry in municipal and industrial areas, in the fresh water supply and in municipal sewage treatment plants.

Those who rely on exceptional longevity and reliability throughout the entire water cycle rely on the comprehensive solutions from Erhard.

Clean work
in the waste water industry

Especially in the waste water sector, in sewage treatment plants and other processes with contaminated and chemically aggressive media, it is important, even more than in other areas, that absolute tightness is guaranteed at critical points such as on lines in maintenance walkways, shafts or at transitions between different process steps.
A long service life as well as the reliable opening and closing of the shut-off butterfly valve even after it has not been used for a longer period of time are requirements of our customers. Simple and fast maintenance or repairs are also an important criterion.

We not only want our products to work cleanly, but also that our customers can work in a clean environment.
signet

Just a few clicks to your desired standard product.

Our product finder will help you find the valve you need.

Not found the right one? Our diversity goes much further and our sales representatives will provide comprehensive consulting on individual solutions.

Sometimes you have to
let off pressure.
Big hydro solutions.

While most water applications operate at low pressure ranges, the big hydro sector is characterised by extremely high pressure ranges and overpressures. The reduction of excess energy is an industry-specific challenge.

That is why we pay particular attention to an optimum choice of valves. For example, fixed cone valves must meet very special requirements with respect to energy reduction as part of the controlled discharge of the reservoir. The energy is converted by means of umbrella-like atomisation, cavitation and vibration problems are avoided and therefore buildings are protected.

Salt applications need increased corrosion protection

Stainless steel is also not safe from corrosion if it is permanently exposed to aggressive media, such as salt, for example in desalination plants. For environments of this type we therefore offer high-quality materials, such as Superduplex, with which corrosion doesn't stand a chance.
banneroverlay
Our topseller for the water & waste water technology
Tosaca-DIN-safety-relief-valve-1400
DIN safety relief valve

Flanged safety valve for the low and high pressure range according to DIN. For a very huge range of applications.

The Tosaca safety valve DIN 1400 is available in different materials and designs and can therefore cover an extreme range of applications.
Because of a big stock of different kind of valve bodys and many different trims, nothing stands in the way of quick deliveries. The valves can also be equipped with other additional options.
Various approvals ensure that these valves are also used in very demanding industries.

Tosaca-DIN-safety-relief-valve-high-pressure-1216HP
DIN safety relief valve high pressure

“Threaded high-pressure safety valve. Readily available for quick delivery and suitable for use in very demanding industries.

Available with a female thread connection BSP or NPT and can be used up to a pressure rating of PN 100. The valves can also be equipped with other additional options.
Because of a big stock of different kind of valve bodys and many different trims, nothing stands in the way of quick deliveries.
Various approvals ensure that these valves are also used in very demanding industries.”

Nozzle check valve CST streamLiner - ChemValve-Schmid
Nozzle check valve streamLiner

The flow-optimised ChemValve-Schmid check valve increases energy efficiency, reduces pressure loss and lowers operating costs.

Furthermore, the seated valve body prevents the valve from tilting and therefore increases the service life of the valve.

The valve is highly sensitive to changes in flow due to its special design, which in turn has a positive effect on hydraulic shocks.

Installation is simplified for all common international flange types due to the housing design.

Ball check valve from Erhard
Ball check valve

The Erhard ball check valve offers backflow protection based on the ball check valve operating principle. In the open position, the sealing ball is pushed out of the flow cross-section by the medium. The Erhard ball check valves are particularly suitable for use in the waste water sector where there is a high risk of clogging.

Advantages:
Erhard ball check valves are resistant to dirt and are extremely maintenance-friendly as the valve works without mechanically moving parts. In addition, the ball check valve has low flow resistance in the open position.

RTValves-DIN-metal-seated-din-gate-valve
Metal seated DIN gate valve

“Metal seated RT Valvole gate valves in cast design are used when minimal pressure drop and/or a bi-directional ON/OFF operation is required.

All standard gate valves have a “”full bore”” because the wedge is completely retracted in the open position. This ensures minimal pressure drop.

Design:
* The housing material is made of cast steel.
* The valves have a bolted or pressure seal bonnet (for higher pressure) to achieve minimal turbulence and flow restrictions.
* Fixed, flexible or split wedge types are available.”

Quadax-4-offset-eccentric-metal-seated-high-performance-quadax-butterfly-valve
4-offset-eccentric metal seated high performance Quadax butterfly valve

“Thanks to its four offset eccentric design and state-of-the-art manufacturing technology, the Quadax valve meets the highest tightness requirements in 100% of cases.
Due to the innovative design principle, even extreme temperatures ranging from –270°C to 800°C are not a problem.

The output cone used on the butterfly is elliptical. The section under a particular angle results in a circular and therefore larger sealing area. As a result, the four offset eccentric high-performance valve is friction-free, has higher Kv values and with absolute tightness.

Available in double flange, lug type, butt weld, gate valve replacement and top entry”

Orbinox-uni-directional-high-performance-knife-gate-valve-HK
Uni-directional high performance knife gate valve

“The knife gate valve type HK from Orbinox is a uni-directional wafer valve for general industrial applications. The gate valve can be used for consistencies up to 5%.

The design of the housing and seat ensures blockage-free shut-off when using fibrous media and media containing solids in many industrial sectors.
The cast sealing ring system (type K) improves the tightness and makes it easier to change seals.”

Orbinox-uni-directional-knife-gate-valve-EX
Uni-directional knife gate valve

“The standard knife gate valve type EX from Orbinox is a uni-directional wafer valve. It is suitable for general industrial applications.

The design of the housing and seat ensures blockage-free shut-off when using suspended solids in many industrial sectors.”

Abwasserschieber-eb-orbinox-540x540
Bi-directional knife gate valve

“The gate valve model EB from Orbinox is a bi-directional wafer type knife gate valve.

The knife gate valve was designed for waste water treatment applications.

The design of the housing and seat ensures blockage-free shut-off when using suspended solids in many areas.”

LDM-din-on-off-and-control-globe-valve-stellite-version
DIN on/off and control globe valve, "stellite" version

“Shut-off control valve with a Stellite seat and a pressure balanced cone (from DN200) as well as linear flow characteristics.

Available with a gland seal or bellows seal.
For nominal diameters from DN15 – DN400
Can be used in temperature ranges of -60°C to +550°C depending on the choice of material.”

JC-metal-seated-din-flanged-ball-valve-long-short-pattern-floating
Metal seated, DIN flanged ball valve, long/short pattern, floating

“The JC Valves ball valve type 3516 / 3540 / 3316 / 3340 is a floating ball valve with a metal seal. It can be designed in both a long or short DIN face to face length.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.

A large selection of materials makes the metal seated, floating DIN flanged ball valve flexible to use. With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries. “

JC-DIN-din-flanged-ball-valve-short-pattern-floating
DIN flanged ball valve, short pattern, floating

“The JC Valves flanged ball valve type 516 / 540 is a floating ball valve according to DIN with a short DIN face to face length.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.

A large selection of materials makes the soft seated, floating DIN flanged ball valve flexible to use.
With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries. “

JC-din-ansi-forged-trunnion-design-soft-metal-seated-flanged-ball-vale
DIN/ANSI forged trunnion design, soft/metal seated, flanged ball vale

“The JC Valves ball valve series 6000 and 7000 are flanged trunnion ball valves according to ANSI or ANSI but with a DIN flange. They can be designed as both soft and metal seated valves.

The standard version of the soft or metal seated flanged ball valve in trunnion design includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing. A large selection of materials makes the ball valve even more flexible.

With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries. “

ICP-3-piece ball valves
3-piece ball valves

The ICP Valves 3-piece ball valves have a 3-piece nody and are made of stainless steel, in a floating version with a full bore valve design.

Connections:
– KH 140: Thread according to DIN 259/2999 (GAS)
– KH 141: Thread according to ASME B1.20.1 (NPT)
– KH 142: Socket weld ends according to ASME B16.11 & DIN 3239 part 2
– KH 143: Butt weld ends according to ASME B16.25 & DIN 3239 part 1
Marking: CE – PED
PN63 (up to 2”) / PN25 (2½“-4“)

Erhard-Control-valve-RV
Control valve

ERHARD control valves type RV are designed for throttling and regulation in water treatment and water distribution plants as well as in hydropower plants. The slotted bush also provides optimum flow behaviour for harmless energy conversion.
The control valve is ideally suited for continuous operation during cavitation.

The ERHARD control valve is available with a handwheel, electric actuator, hydraulic or pneumatic piston actuator. A straight or angle version is possible.

Erhard-non-slam-nozzle-check-valve
Non slam nozzle check valve

ERHARD nozzle check valves are designed for universal use and are particularly economical check valves for untreated and potable water as well as purified waste water due to their design.

Special features include the ultra-low pressure loss due to optimised flow cross-sections, a flow-efficient valve disc and valve stem gasket, as well as optimum hydraulic behaviour with short closing travel to minimise pressure surges.

Erhard-double-eccentric-butterfly-valve-ROCOwave
Double eccentric butterfly valve

The double eccentric butterfly valve ROCO wave is designed for water applications.

The valve is characterised by high energy efficiency, a flow-optimised design, minimal pressure losses and continuous corrosion protection.
The connection between the shaft and valve disc is covered by a polygon connection.

The double eccentric butterfly valve has a modular actuator concept through the use of a handwheel, electric actuator, stem extension, weight-loaded hydraulic actuator, pneumatic actuator or chainwheel.

ChemValveSchmid-wafer-type-swing-check-valve-CSCxCSCF
Wafer type swing check valve

The check valve CSC / CSCF offers efficient performance in a small space.

A robust shaft and a defined end stop guarantee an above-average service life. The angled shaft seat ensures improved seat tightness even at low pressures. The valve can also be equipped with a spring that supports the closing process. The large number of turns of the optional spring prevents overloading and guarantees long-lasting durability.

The check valve CSC / CSCF can be used in all industrial processes with liquids, gases and steam.

TTV Wafer / lug type butterfly valve
Wafer / lug type butterfly valve

The TTV centric flanged / double flanged butterfly valve is available in a wide range of materials.

Depending on the application, the seats are available in the most common material EPDM or NBR, but also in different types of silicone, Hypalon, Nordel, Viton and many others.

Suitable for all industries and the most diverse applications due to the different choice of seats.

Depending on the application, available in the most common material EPDM or NBR and in different types of silicone, Hypalon, Nordel, Viton and many others.



Needle valve

ERHARD needle valves are innovative valves for the safe control of pressure stages and flow rates.

The control valves type RKS/RKV are characterised above all by optimised flow behaviour and ultra-low pressure losses when fully open. The control range can extend up to 96%.

There are different control inserts for each area of application in order to cover all operating cases: a vaned ring, slotted cylinder, pipe cylinder and other special inserts.

The needle valves have a wide main seal in the cavitation-free space and also an additional shaft seal.

ANSI cast trunnion design, flanged ball valve, soft/metal seated

“The JC Valves ball valve type 2515 and 2530 are flanged cast trunnion ball valves according to ANSI Class 150 or 300 respectively. They can be designed as both soft and metal seated valves. A large selection of materials makes the ball valve even more flexible.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.

With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries. “

Soft seated, ANSI flanged ball valve, floating

“The JC Valves ball valve type 560 / 560B / 660 / 600B is a floating ball valve according to ANSI Class 600 and can either be designed with a full or reduced bore. A large selection of materials makes the ball valve even more flexible.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.
With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries. “

Digital (electro-pneumatic) positioner

The Digital (electro-pneumatic) positioner TZID-C from ABB is an electronically parametrisable and communication-enabled positioner for mounting on pneumatic linear and part-turn actuators.

It is characterised by a small, compact modular design and an excellent price-performance ratio. The adjustment to the actuator and the determination of the control parameters are performed fully automatically, thus achieving the greatest possible time savings and optimum control behaviour.

Digital (electro-pneumatic) positioner EDP300

The digital (electro-pneumatic) positioner EDP300 from ABB is an electronically parametrisable and communication-enabled positioner for mounting on pneumatic linear and part-turn actuators.

It is characterised by a small, compact modular design and an excellent price-performance ratio.

The adjustment to the actuator and the determination of the control parameters are performed fully automatically, thus achieving the greatest possible time savings and optimum control behaviour. It has a wide range of diagnostic possibilities as well as option modules and enhancements.

ANSI metal seated flanged ball valve, floating

“The JC Valves ball valve type 3515 / 3530 is a floating ball valve according to ANSI with a metal seat. It is a flanged ball valve for ANSI piping.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing. With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries. Another advantage is the large selection of materials that makes the ball valve even more flexible. “

Double eccentric, high performance butterfly valve Colossus Colossus
Double eccentric, high performance butterfly valve Colossus

Die Doppelexzentrische Hochleistungs-Absperrklappe bietet eine dichte Absperrlösung für die anspruchsvollsten Anwendungen.

Weitere Varianten im Programm: Konzentrische, doppelt exzentrische und dreifach exzentrische Ausführung.

Check valve

ERHARD check valves are tried and tested double offset valves in a short weight-saving length.

The freely oscillating valve disc has a flow-friendly design. The shaft bearings are designed to be maintenance-free and self-lubricating.
Further advantages include the rolled up, solid housing seat ring and the disc seat ring with an elastic fine seal.
These check valves are also available with a hydraulic damping device.

Pneumatic rack-and-pinion actuator

Actreg is a manufacturer of double piston part-turn actuators in aluminium housings with torques of up to 6,500 Nm.

The pneumatic rack-and-pinion actuator from Actreg offers reliable automation for valves with 90° swivel movement.

Designed and produced to withstand most applications and environmental conditions, the high precision in terms of design and quality provides long and safe operating performance.

In order to support its customers in the safe control of their processes, ACTREG relies on strict quality assurance thanks to state-of-the-art processing and testing facilities.

Pneumatic scotch yoke actuator

Actreg is a manufacturer of pneumatic Scotch Yoke actuators for high-performance applications up to 700,000 Nm.

The products offer reliable automation for valves with 90° swivel movement.

Designed and produced to withstand most applications and environmental conditions, the high precision in terms of design and quality provides long and safe operating performance.

In order to support its customers in the safe control of their processes, ACTREG relies on strict quality assurance thanks to state-of-the-art processing and testing facilities.

3-way ball valve, soft seated, compact design

Due to its compact design, the Adler 3-way ball valve is a space-saving variant of the flanged 3-way ball valves.

The ball is fully bored and can be designed with an “L” or “T” bore. The valve is made of steel or stainless steel and can be produced as a wafer design ball valve or with female thread.

Compact ball valve, soft seated

Due to its compact design, the compact Adler ball valve (Type FA1/FB1/FC1/FA2/FB2/FC2) is a space-saving variant of the flanged way ball valves.

The valve is made of steel or stainless steel and can be produced as a wafer or flanged ball valve. Depending on the type, the valve is made of cast or solid material.

The compact Adler ball valve is used in all industries.

Electric multi-turn and part-turn actuators

In order to ensure that liquids, gases, steam and granulate flow through pipes in process engineering plants and that their flow rates on the transport routes are also optimally controlled, positioners position the valves between the open and closed state. The valves are operated remotely from the control room with AUMA actuators.

AUMA covers a torque range from 10 Nm to 32,000 Nm with the product range of the SA type rotary actuators and a torque range of 50 Nm to 2,400 Nm with the product range of SQ type part-turn actuators.

AUMA electric rotary actuators are used for the automation of butterfly valves or gate valves, for example. They are the most flexible products in the AUMA family. AUMA electric part-turn actuators are used wherever a swivel movement of < 360 degrees has to be realised, as with butterfly valves and ball valves.

3-way control valve

The Badger Meter 3-way control valve RC230 stands for very precise control.

It is particularly suitable for the control of liquids, gases or steam in general industry, research, development and pilot plants.

Due to its compact size, this 3-way control valve is particularly suitable for the dosing of additives, for sampling and for hydraulic systems with small flow rates. The valve is designed as standard with an NPT female thread.

Flanged globe style control valve

The Badger Meter flanged flow control valve is suitable for the control of medium to ultra-small flow rates when using liquids, gases or steam in general industry, research, development and pilot plants.

Due to its compact size, it is particularly suitable for the dosing of additives, for sampling and for hydraulic systems with small flow rates.

Standard angle control valve

The standard angle control valve RC220 is used for the control of liquids, gases or steam in general industry, research, development and pilot plants.

Due to its compact size, it is suitable for medium to small flow rates and is reliable for the dosing of additives, for sampling and for hydraulic systems with small flow rates.

It is designed as standard with an NPT female thread.

High pressure control valve

The high-pressure control valve type HP-10 is used wherever the standard type RC200 comes to its limits due to too high pressure.

The high-pressure control valve type HP-10 is the right valve for liquids and gases in high-pressure applications with medium to small flow rates and is available as a globe or angle valve.

Butterfly valve Hydromat®

Der HYDROMAT® ist eine extrem robuste Absperrklappe mit zentrisch gelagerter Klappenscheibe, die durch bewährte konstruktive Merkmale eine jahrzehntelange Betriebssicherheit gewährleistet und somit Kosten spart, da keine unnötigen Reparaturen anfallen.

ANSI safet relief valve

The flanged safety valve according to ANSI is suitable for the low pressure and high pressure range. The valve is very versatile in use.

With options in a wide range of materials and designs, the Tosaca safety valve covers an extremely wide range of requirements.

Because of a big stock of different kind of valve bodys and many different trims, nothing stands in the way of quick deliveries. The valves can also be equipped with other additional options. Various approvals ensure that these valves are also used in very demanding industries.

DIN und ANSI Sicherheitsventil für den Niederdruckbereich
Die Type 1216B ist ein geflanschtes Sicherheitsventil für den Niederdruckbereich in DIN und ANSI. Flexibilität in der Ausführung. Diese Ausführung ist auch in der Kombination Flansch-am-Eintritt und Gewinde-am-Austritt verfügbar jeweils in DIN und ANSI als auch gemischt. Durch lagernde Gehäuse und vieler verschiedener Innengarnituren steht einer schnellen Lieferung nichts im Wege. Weiters können die Vetile auch noch mit anderen Zusatzoptionen aufgerüstet werden. Verschiedene Zulassungen stellen sicher, dass diese Armaturen auch in sehr anspruchsvollen Industrien zum Einsatz kommen.
DIN safety relief valve, low pressure, threated

Threaded safety valve for the low pressure range from the type 1216.

Readily available for quick delivery and suitable for use in very demanding industries.

Available with a female thread connection BSP or NPT. This version is also available as standard in Duplex.
Because of a big stock of different kind of valve bodys and many different trims, nothing stands in the way of quick deliveries.
The valves can also be equipped with other additional options.
Various approvals ensure that these valves are also used in very demanding industries.

Barstock control valve

The barstock control valve has been specially developed for applications in reverse osmosis plants.

The barstock control valve type RC250 is suitable for the control of medium to ultra-small flow rates when using liquids, gases or steam in general industry, research, development and pilot plants.

Due to its compact size, it is particularly suitable for the dosing of additives, for sampling and for hydraulic systems with small flow rates.

It is designed as standard with an NPT female thread.

Standard control valve

The standard Badger Meter control valve RC 200 is suitable for the control of medium to ultra-small flow rates when using liquids, gases or steam in general industry, research, development and pilot plants.

Due to its compact size, it is particularly suitable for the dosing of additives, for sampling and for hydraulic systems with small flow rates.

It is designed as standard with an NPT or a BSP-P female thread.

Plastic butterfly valve

The CEPEX plastic butterfly valves can be used to shut off and control liquids.

The valves made entirely of plastic have the advantage that they are resistant to chemicals. The EXTREME series is designed for special requirements and can therefore be used in steel plants, chemical plants or the oil industry.

The plastic butterfly valve can be operated either manually or also automatically and is available in a wide variety of plastics (PVC-U, CPVC, PP-H, PVDF and ABS).

Plastic ball valve

The plastic CEPEX ball valves can be used both to shut off and control liquids.

The ball valves made entirely of plastic bring advantages in terms of resistance to chemicals. The EXTREME series is designed for special requirements and can therefore be used in steel plants, chemical plants or the oil industry.

The plastic ball valves can be operated either manually or also automatically. The model is available in a wide variety of plastics (PVC-U, CPVC, PP-H, PVDF and ABS).

Plastic diaphragm valve

The plastic CEPEX diaphragm valves can be used both to shut off and control liquids.

The ball valves made entirely of plastic bring advantages in terms of resistance to chemicals. The EXTREME series is designed for special requirements and can therefore be used in steel plants, chemical plants or the oil industry.

The plastic diaphragm valves can be operated either manually or also automatically. The model is available in a wide variety of plastics (PVC-U, CPVC, PP-H, PVDF and ABS).

CeraValve ceramic lined ball valve

Cera Valve offers wear and corrosion-resistant ceramic lined ball valves for on/off and control functions.

The use of ceramic-lined valves make sense wherever standard valves reach their limits (abrasion, corrosion, temperature and pressure).

A large selection of variuos ceramic materials allows for solutions for almost all industrial sectors. Special adaptations and special applications are also solved in close cooperation with our customers.

CeraValve partially ceramic lined ball valve

The ball valve BR 26 CERA is a stainless steel ball valve for on/off functions only with ceramic seats and a ceramic ball for use in less abrasive and low corrosive applications.

The basic principle is based on the “floating ball” design. The seats are pressed against the ball by O-rings. This valve can be supplied with a manual handle with a pneumatic or electric actuator.

CeraValve ceramic lined sliding disc valve

Cera Valve offers wear and corrosion-resistant sliding disc valves for on/off and control functions.

The medium flows exclusively in ceramic with this design. It is therefore suitable for highly corrosive media.

Other advantages: very good control of small amounts of media containing solids and completely cavity free.
A large selection of ceramic materials allows for solutions for almost all industrial sectors.

Special adaptations and special applications are also solved in close cooperation with our customers.

The ceramic lined sliding disc valve is used in waste incineration plants:
– Dosing of HCI washing water (pre-washer)
– Dosing of limewash to the absorber (pH regulation, desulfurisation)
and in the chemical industry as an – Alternative to PTFE / PFA lined valves if a medium is abrasive and / or prone to diffusion.
– Alternative to valves made of special materials. (e.g. Hastelloy, titanium, etc.)

Dual plate check valve

The ChemValve Schmid dual plate check valve has an eccentric disc and a wafer design.
The flow-friendly design reduces the pressure loss in the system and therefore the energy requirements of the plant.

Another advantage of this valve is that no gland is required due to the design and so it is impossible for the medium to escape.

The dual plate check valve is used in all industrial processes involving liquids, gases or steam.

Analog positioner

The V200 is an analogue and electrpneumatic positioner for mounting on pneumatic linear and part-turn actuators. It is characterised by a compact, robust modular design and an excellent price-performance ratio.

The adjustment to the actuator is carried out by means of cam discs and mechanical screws, so that simple adjustments are possible and good control behaviour can be achieved.

Digital positioner

“The Sipart PS2 is an electronically parametrisable and communication-enabled positioner for mounting on pneumatic linear and part-turn actuators. It is characterised by a small, compact modular design.

The adjustment to the actuator and the determination of the control parameters are performed fully automatically, thus achieving the greatest possible time savings and optimum control behaviour. It has a wide range of diagnostic possibilities as well as option modules and enhancements.”

Fail safe electric actuator

“The Schiebel electric actuators with spring return ofthe FS and FSQT series are electric actuators that move or remain in a predefined position because of a spring. This reset is based on a purely mechanical principe, without hydraulics or a battery.

In addition, no initialisation stroke is necessary due to the design and the actuator can be used for regulation purposes without any concerns as the fail-safe unit is decoupled.”

Compact electric actuator with integrated control unit

“The Schiebel electric actuator series CM combines a compact and lightweight design with an integrated control unit.

The built-in control unit can be extended simply and easily by means of software enablements.
Due to the high power density of the motor, the CM series has very compact dimensions.
In addition, these actuators have a lower weight due to the chosen material.

Alternatively, it is possible to use special materials (e.g. bronze, steel).

Due to its high protection class, the electric actuator CM can be used virtually anywhere.”

Metal seated DIN swing check valves

“RT gate valves valvole in cast design are used to prevent backflow in pipe systems. Due to their fully open design, this results in minimal pressure drop.

Design:
* The housing material is made of cast steel. The valves have a bolted or pressure seal bonnet (for higher pressure).
* The valve disc is made with forged material. On request, the disc can be supplied with an overlay of Stellite or other materials.
* The disc hinge joint is designed in such a way to achieve a
perfect tightness, which means a self-positioning disc system. “

Pinch valve aiRFlex®

“The aiRFlex® pinch valve is designed for abrasive, corrosive and scaling sludge, liquids and powders.

It is characterised by a full bore and it is interchangeable with most ball valves and diaphragm valves.

Technical advantages:
* Patented expansion folds prevent stretching. This reduces the stress on the tube and significantly increases the service
life
* No moving parts – tube is the only wear part.
* Trouble-free operation – no blocking or clogging.
* Increased service life of the tube, which does not stretch when closed.
* Cost-effective solutions as no actuator is required.
* The tube can be replaced without having to remove the valve from the line, thus guaranteeing low maintenance and operating costs.

Operating pressure about 2 bar below
the available factory air supply, up to
max. 6 bar.
The MONSYS monitoring system prevents
unexpected emergency repairs.

Slurry bi-directional knife gate valve with rubber sleeves

“The knife gate valve type VG from Orbinox is a bi-directional wafer valve equipped with two sealing sleeves with a steel core.

The valve was designed for media containing solids and abrasive media.
The valve type VG can be used for a wide range of industrial applications.”

Uni-directional knife gate valve

“The knife gate valve from Orbinox type ET is a uni-directional knife gate valve for industrial applications according to MSS-SP-81 and TAPPI TIS 405-8 standards.

The design of the housing and seat ensures blockage-free shut-off when using suspended solids in many industrial sectors.”

Bi-directional knife gate valve, stainless steel

“The knife gate valve model EB from Orbinox in a stainless steel design is a bi-directional knife gate valve designed for general industrial applications.

The design of the housing and seat ensures blockage-free shut-off when using suspended solids in many areas.”

DIN strainer

“The flanged strainers FP 110, 210, 220, 230 are pipe elements to clean mechanical impurities out of the medium.

The strainers excel with a robust body construction made of stainless steel and the possibility to clean the media without having to dismantle the bonnet.

The LDV Valves DIN strainer valves are designed with an angle seat and a flange connection.
The strainer valves are available in different mesh sizes and lengths according to DIN 558-1 GR 1.
Depending on the type, different housing materials are available such as GG25, GGG40, 1.0619, 1.4581 and others are available on request. The strainer material is stainless steel.

ATEX, TA-Luft certificates as well as oil and grease-free versions are available on request.”

DIN piston check valve

“LDM piston check valves are self-acting valves to prevent unwanted backflows. They are designed for long-term and maintenance-free operation.

Depending on the version, the valves are closed by the weight or by an additional spring.
These models are also available in oil and grease-free versions.
Nominal diameters from DN15 – DN200
Nominal pressure PN16-PN40
Temperature range of -10°C to +400°C

DIN on/off and control globe valve

“Shut-off control valve with a pressure balanced cone (from DN200), linear flow characteristics and a position indicator.

Available with a gland seal or bellows seal.
The valve can optionally be designed with a control cone or without oil and grease.
For nominal diameters from DN15 – DN400.
Can be used in temperature ranges of -60°C to +550°C depending on the choice of material. “

Square port knife gate valve for solid loaded fluids

The knife gate valve type BC from Orbinox is a square or rectangular port low-pressure knife gate valve in welded design for liquids containing solids and solids and is mainly used in bulk handling and silo outlet applications. It is generally used for media such as liquids with solids, granulate, powders and other materials.

Round swing flap gate penstock

“The Orbinox round flap gate type RR is a valve without a housing that is primarily used for waste water, irrigation, hydropower and similar applications.

The round flap gate valve is made of stainless steel with an elastomer seal for tight shut-off.

The valve is available in different dimensions and for different pressures.”

Rectangular swing flap gate penstock

“The square flap gate type RC from Orbinox is a valve without a housing that is primarily used for waste water, irrigation, hydropower and similar applications.

It is made of stainless steel with an elastomer seal for tight shut-off.

The valve is available in different dimensions and for different pressures.”

Metal-to-metal seat wafer style tilting disc check valve

“The Orbinox metal seated check valve type RM is a robust tilting disc check valve with an oblique seating angle. It is used in all industries, but mainly in the pulp and paper, water treatment and food sectors.

In addition to the short length, it is characterised by a low pressure drop and opening pressure. Another advantage is the reduced pressure surges caused by the quick closing action (oblique seating).
An optional spring accelerates the closing action. “

Channel penstock

“The Orbinox channel gate type CC is designed with a 3-sided sealing and for use in waste water technology, irrigation, hydropower utilisation and similar areas of application.

The channel gate is a welded design in stainless steel (1.4301 / 1.4571) with a bolted-on elastomer seal.

The model offers many design options for different dimensions and operating pressures.

Actuator types: Manual operation, electric actuator, hydraulic actuator.”

Fixed cone valve

“The Orbinox fixed cone valve type CH is a special round valve for the shut-off or control of water in dams, pumping processes and in hydropower plants.

The gate valve in a sturdy welded design is available in many design options depending on the dimensions, operating pressure or required material. “

Wall mounted penstock

“With the wall penstock type MU, Orbinox offers a wall penstock with a four-sided sealing penstock for fixing to the wall for waste water technology, irrigation, hydropower utilisation and other applications.

Welded design in stainless steel (1.4301 / 1.4571) with a bolted-on elastomer seal.
Many design options for different dimensions and operating pressures.

Actuator types: Manual operation, electric actuator, hydraulic actuator.”

Valve for hydraulic works, bonneted gate

“The control and gate valve from Orbinox is a special rectangular valve for the shut-off or control of water in dams, pumping processes and in hydropower plants.

The gate valve is a sturdy welded design and offers a variety of design options to suit the dimensions, operating pressure or required material.

Actuator types: Hydraulic, electric actuator, manual operation.”

LDM Valves, 2- und 3-Wege Regelventile

“Straight and 3-way type control valve with a mixing or distribution function.

Housing material: Spheroidal cast iron, cast steel, stainless steel.
Turndown ratio: 50:1
Optionally with bellows, LDM spline, perforated cone,
Oxygen and food-compatible design available
Nominal diameters: from DN15 – DN300, PN16 – PN40
Temperatures: from -20°C to +500°C
Leakage rate class: III/IV according to EN1349
Length according to EN 558-1
Approvals: CE, ATEX, ISO9001:215, TRD100/110/201, TRB 801, ISO14001:2015, OHSAS”

Soft seated, butterfly valve

“The Emreson resilient seated butterfly valve is a centric butterfly valve with a split shaft (up to DN300), rounded polished disc edge, centring bores on the valve housing and an extended valve neck allows for pipe insulation.

The type GRW is designed as a wafer type valve and the GRL as a flanged type valve according to EN558 series 20, with a spheroidal cast iron housing and a disc in 1.4408 steel. “

Metal seated, 3-piece ball valve

“The JC Valves type 3800 is a solid 3-piece ball valve with a metal seat that can be used for high pressures of up to 140 bar.

Due to its modular design, the metal seated 3-piece ball valve can be used in many different ways and can be supplied with various connections, both bolted and welded ends. A large selection of materials opens up a wide range of applications.
Thanks to a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3), this monoblock ball valve can be used in virtually all industries.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.”

Metal seated, forged monobloc ball valve

“The JC Valves type UDV is a metal seated monoblock ball valve that can be used for high pressures up to 240 bar.
The valve is uni-directional and can be designed with both bolted and welded ends.
The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.
Thanks to a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3), this monoblock ball valve can be used in virtually all industries. A large selection of materials opens up a wide range of applications. “

Soft seated, forged monobloc ball valve

“The JC Valves type 400 and 41500 is a forged monoblock ball valve that can also be used for high pressures up to 240 bar.

The standard version of the soft seated monoblock ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.
The valve can be designed with both bolted and welded ends.

Thanks to a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3), this monoblock ball valve can be used in virtually all industries. A large selection of materials opens up a wide range of applications. “

Metal seated, DIN flanged ball valve, long pattern, floating

“The JC Valves metal seated ball valve type 3563 / 3599 is a floating flanged ball valve with a metal seat and long DIN face to face length.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.

With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries. A large selection of materials makes the flanged ball valve flexible to use. “

Soft seated, DIN flanged ball valve, long pattern, floating

“The JC Valves soft seated flanged ball valve type 563 / 599 is a floating ball valve according to DIN with a long DIN face to face length.

The standard version of the soft seated, floating DIN flanged ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.

With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries. A large selection of materials makes the flanged ball valve flexible to use. “

Soft seated DIN flanged ball valve, long pattern, floating

“The JC Valves flanged ball valve type 316 / 340 is a floating ball valve according to DIN with a long DIN face to face length.

The standard version of the soft seated, floating DIN flanged ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.

With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries. A large selection of materials makes the flanged ball valve flexible to use. “

DIN flanged ball valve, semi trunnion, long/short pattern series

“The JC Valves type 1516 / 1540 / 1316 and 1340 are flanged ball valves according to DIN with a trunnion bearing in long or short pattern.

This type is used when a floating ball valve reaches its limits, but a trunnion ball valve is not necessary. This variant is therefore a version that combines the advantages of the floating ball valve and those of the trunnion ball valve and fills the gap between the two.

It is important to note that the seat in these models is not live loaded and is therefore not innately pressed onto the ball.

The standard version of the DIN flanged ball valve with a trunnion mounted ball includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.

The large variety of materials opens up a wide range of applications for this series.
With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3), it can be used in virtually all industries. “

DIN flanged ball valve with heating jacket, long pattern, floating

“The JC Valves ball valve type 553 is a flanged ball valve with an integrated heating jacket. The heating jacket prevents the hardening or viscous medium damaging the valve at low temperatures.

The standard version of the flanged ball valve according to DIN with a heating jacket includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.

A large selection of materials makes the ball valve 533 very flexible to use.
With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries.

Soft seated 3-piece flanged ball valve, floating

“The JC Valves ball valve type 916N is a flanged 3-way ball valve for DIN piping and is made of steel or stainless steel.
The ball is fully bored and can be designed with an “L” or “T” bore.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.
With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3), the soft seated floating 3-way flanged ball valve can be used in virtually all industries. “

ANSI piston check valves

“The JC Valves piston check valve R800 is designed with either bolted (NPT) or welded (SW) ends.

The piston check valve is mainly used in the oil and gas, chemical, petrochemical, energy and mining industries.”

Soft seated, ANSI flanged ball valve, floating, full bore

“The JC Valves ball valve type 590B and 550B are floating flanged ball valves according to ANSI Class 600 or 1500 respectively.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.
Another advantage is the large selection of materials that makes the ball valve even more flexible.

With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries. “

Soft seated, ANSI flanged ball valve, floating

“The JC Valves ball valve type 515 / 515B / 530 / 530B is a floating ball valve according to ANSI. It is also a flanged ball valve for ANSI piping.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing. A large selection of materials, which makes the ball valve even more flexible, is another advantage of the JC Valves ball valves.

With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3, and many others), it can be used in virtually all industries. “

ANSI flanged ball valve, semi trunnion

“The JC Valves types 1515 and 1530 are flanged ball valves according to ANSI with a semi-trunnion bearing. It is important to note that the seal is not live loaded and is therefore not innately pressed onto the ball.

This type is used when a floating ball valve reaches its limits, but a trunnion ball valve is not necessary. This variant is therefore a version that combines the advantages of the floating and those of the trunnion ball valve and fills the gap between these two.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing. With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3), it can be used in virtually all industries. Another advantage is also the availability of a large selection of materials that makes the ball valve even more flexible. “

ANSI double block and bleed ball valve, floating

“The JC Valves “double block & bleed” (DBB) valves are designed and produced to provide a reliable alternative to multi-stage shut-off valves.

They reduce the possible leakage points, lower installation and maintenance costs.
Combining all the shut-off and drain components within a valve leads to a significant reduction in weight and piping.

The valves are either available in a flanged or bolted design.”

Soft seated 3-piece flanged ball valve, ANSI, floating

“The JC Valves type 915N is a flanged 3-way ball valve for ANSI piping.

The ball is fully bored and can be designed with an “L” or “T” bore. The valve is made of steel or stainless steel.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing. With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3), it can be used in virtually all industries.”

Limit switch box

In addition to our Eurotec main products, the wave and i-Box, we also have all the other Eurotec limit switch boxes in our range.

flex Box: Nomen est omen – this model is particularly flexible and is suitable for harsh conditions with particular requirements for stability and load capacity as well as for applications with a salty atmosphere, sulfur gases and ammonia nitrate.

neptun: made of high-quality stainless steel, it is particularly resistant to corrosion and pitting. For use in offshore applications, the chemical industry and environments with a salty atmosphere, sulfur gases, ammonia nitrate and numerous other aggressive media.

big Box: For large cylindrical sensors with an M30 thread or special length.

Eurobox: For larger and above all longer sensors.

These include the d-Box, the neptun, the Eurobox, the flex model as well as the big box or the plastic version.

Please visit the manufacturer’s website or contact one of our team for more information on these products.

Soft seated 3-piece ball valve

“The JC Valves 800 series is a solid 3-piece ball valve that can also be used for high pressures up to 140 bar. Due to its modular design, the ball valve can be used in many different ways and can be supplied with various connections, both bolted and welded ends. Another advantage is also the availability of a large selection of materials that makes the ball valve even more flexible.

The standard version of the ball valve includes a anti-blow out stem, an antistatic device, a pressure balancing cavity hole and a “”live loaded”” packing.

With a wide range of approvals (Fire Safe, Fugitive Emission, ATEX, TRCU, CRN, SIL 3), it can be used in virtually all industries. “

Electric part-turn actuator

“The J4C series is one of the leading electric part-turn actuators and offers many possibilities with its fully digital electronics. The actuator can be configurated precisely to your needs. The integrated RBG status LED always shows the actual operating state by means of different colours and flashing cycles.
In addition to brushless motors, the robust plastic housing, moreover J+J actuators are very user-friendly.

All model sizes from 20 Nm to 300 Nm are designed for input voltages range from 24 V to 240 V AC/DC. They are also optionally available for an input voltage of 12 V AC/DC.”

Limit switch box

“The all-rounder: flexible, compact and easy to stock.

The wave limit switch box was developed in 2008 and is still produced exclusively in Germany today.

The Eurotec wave is very flexible with its classic design. It accommodates 1-4 mechanical microswitches and sensors in the V3 design. Slot initiators and cylindrical sensors (max. diameter 18 mm / max. length 50 mm) can also be installed.

The housing is available in polyamide, Vestamid and aluminium. All versions of the wave series achieve protection class IP67 due to the curved bonnet.
There is a low-cost version with a very stable glass fibre-reinforced plastic bracket and a chemical version with our high-quality stainless steel bracket MBHV.
All brackets are height and width adjustable and are included as standard.”

Limit switch box
Compact, simple and efficient. The i-box is produced by the quality manufacturer Eurotec in Germany. Thanks to its sophisticated mounting system, it can be quickly and easily installed directly on the actuator and is therefore extremely space-saving. Despite its very compact design, it offers space for 1 to 2 mechanical toggle switches or inductive sensors in the V3 design. Its large OPEN-CLOSED display is still visible even from a distance. Alternatively, it can be equipped to display T or L-bores. The standard version is suitable for an 80x30 mm actuator bore pattern with shaft heights of 20 and 30 mm. The height and width adjustable stainless steel bracket IMBHV is required for other bore patterns. The i-box housing achieves protection classes IP66 and IP67 according to DIN EN 60529.
Diaphragm valve

ERHARD diaphragm valves are designed for on-off, controlling and monitoring and are therefore industrial valves suitable for individual applications.

The type FD has a full port. It is characterised by tight closing even with particles in the media. The hood and pressure piece do not come into contact with the medium. These diaphragm valves are also equipped with lift restriction as standard.

The diaphragm valves are available with numerous actuator types for manual and automatic operation. These valves are designed for universal use due to the combinations of housing and diaphragm materials individually adapted to the medium.

Erhard-Ball valve
Ball valve

ERHARD ball valves are characterised by a full port, a low overall height and a low-flow design with ultra-low pressure loss for energy-saving and economical operation.

The design principle is a double offset with a free-flowing ball plug. It is designed as a bi-directional valve. The profile ring is in the open position outside the flow. The ERHARD ball valve is also equipped with a robust sealing section with a non-sensitive surface.

Air valve

The TWIN AIR air valve from Erhard regulates the automatic venting of water pipes in plants, buildings and shafts and guarantees automatic venting of the pipe during filling, operational venting and emptying processes.

It is characterised by a compact design and low weight as well as a large cross-section, which enables ultra-high venting speeds.
The operating principle: Valve for automatic air release and air admission via a lever and with patented self-cleaning at each switching operation.

The valve is enamelled on the inside and has an epoxy coating on the outside. It is also available for seawater applications.

Double eccentric butterfly valve

The double eccentric butterfly valve EAK is used in water applications with large nominal diameters.

The butterfly valve offers a modular actuator concept through the use of a handwheel, electric actuator, stem extension, weight-loaded hydraulic actuator, pneumatic actuator or chainwheel.

Disc check valve

The check valve CSD / CVD is robust, economical and reliable. The solid and efficient design ensures low overall costs.

Furthermore, the form-fitting connection of the spring cap to the housing secures all moving parts. In addition, the opening pressure can be individually adjusted by using different springs. Thanks to the valve plate guide through the ribbed housing, a longer service life can be achieved.

The check valve is used for liquids, gases and steam in all industrial processes.

Xtreme disc check valve forged

The forged ChemValve-Schmid check valve DSL is designed for high pressure and high temperature environments due to its special housing design.

The wide range of different materials allows to use it for corrosive media and operating temperatures up to 500°C.

The check valve DSL can be used in all industrial processes with liquids, gases and steam.

Limit switch box

Compact, simple and efficient.

The i-box is produced by the quality manufacturer Eurotec in Germany. Thanks to its sophisticated mounting system, it can be quickly and easily installed directly on the actuator and is therefore extremely space-saving. Despite its very compact design, it offers space for 1 to 2 mechanical toggle switches or inductive sensors in the V3 design.

Its large OPEN-CLOSED display is still visible even from a distance. Alternatively, it can be equipped to display T or L-bores. The standard version is suitable for an 80×30 mm actuator bore pattern with shaft heights of 20 and 30 mm. The height and width adjustable stainless steel bracket IMBHV is required for other bore patterns. The i-box housing achieves protection classes IP66 and IP67 according to DIN EN 60529.

Solenoid valve & pneumatic accessories

Hafner-Pneumatik is a leading European manufacturer of a complete range of pneumatic control valves. In addition to solenoid valves and pneumatic valves, they also offer pneumatic control systems and valve linking modules; moreover, they have specialised in the production of individual special solutions.

The highest product quality, flexibility and excellent customer service are the cornerstones of the company’s philosophy. The products are not only found in mechanical engineering and automation technology, but also in vehicle technology and the process industry. Hafner-Pneumatik stands for more than 30 years of experience in the development of pneumatic components for industry!

Centric flanged / double flanged butterfly valve
Double eccentric , double flanged butterfly valve
