Find the right gate valves or wedge gate valves with just a few clicks!

Our valve finder will help you find the right butterfly valve and control valve for your requirements. Searched and not found? Our range goes much further. For special products and individual advice, please contact us directly.

`

Filter the results

Showing all 5 results

    ANSI gate valve

    Type VC150BB / VC300BB / VC600BB / VC900BB / VC1500BB / VC2500BB / VC900PS / VC1500PS / VC2500PS (JC Valves)
    Pressure: 10 - 172bar
    Nominal size: 2" - 36"

    “The JC Valves gate valves are designed with either a bolted or pressure seal bonnetand a flexible wedge. The valve can be produced with nominal diameters greater than 2 1/2”.

    The valve is designed with an outside screwed stem and according to ANSI.

    This gate valve is mainly used in the oil and gas, chemical, petrochemical, energy and mining industries.”

    ANSI gate valve, forged design

    Type VC150BB / VC300BB / VC600BB / VC900BB / VC1500BB / VC2500BB / VC900PS / VC1500PS / VC2500PS (JC Valves)
    Pressure: 10 - 172bar
    Nominal size: 2" - 36"

    “The JC Valves gate valves are designed with either a bolted or pressure seal bonnet and a flexible wedge. The valve can be produced with nominal diameters greater than 2 1/2”. The valve is designed with an outside screwed stem and according to ANSI.

    The JC Valves ANSI gate valves are mainly used in the oil and gas, chemical, petrochemical, energy and mining industries.”

    DIN gate valve, small body metal seat

    (BFE Bonney Forge)
    Pressure: 40
    Nominal size: 15 - 50

    The BFE (Bonney Forge) metal seated, small shut-off gate valve has an outside screwed rising stem, solid wedge and flange connection.

    The gate valves are forged and used for non-aggressive liquids, steam and gas.

    DIN high pressure, double plate wedge gate valve

    Type ZO40 / ZO100 / ZS63 / ZK63 / ZS100 / ZK100 / ZS160-400 (Wakmet)
    Pressure: 40 / 63 / 100 / 160 / 250 / 320 / 400 / 500 / 630
    Nominal size: 50 - 500

    The forged welded design of the metal seated DIN high-pressure gate valves are made of forged steel with a gland seal or bellows seal prevents material defects such as cracks or porosity.

    This type of design ensures that non-metallic impurities are eliminated or excluded.

    Wakmet protects the valve against overpressure with a safety valve unit. This type of construction allows easier isolation of the gate valve and direct access to the preset safety valve.

    Axial bearing for easier opening/closing of the valve.

    This valve is mainly used in the energy sector and in the area of the pulp and paper industry.

    Metal seated DIN gate valve

    Type 205-505 / 210-510 / 235-535 / 240-540 / 240-540 / 250-550 / 250-550 / 260-560 / 260-560 / 261-561 / 267-567 (R.T. Valvole)
    Pressure: 10 / 16 / 25 / 40 / 63 / 100 / 160 / 250 / 320
    Nominal size: 50 - 1000

    “Metal seated RT Valvole gate valves in cast design are used when minimal pressure drop and/or a bi-directional ON/OFF operation is required.

    All standard gate valves have a “”full bore”” because the wedge is completely retracted in the open position. This ensures minimal pressure drop.

    Design:
    * The housing material is made of cast steel.
    * The valves have a bolted or pressure seal bonnet (for higher pressure) to achieve minimal turbulence and flow restrictions.
    * Fixed, flexible or split wedge types are available.”
